TJG fixed lifting feeder
Overview
TJG series of fixed lifting feeder consists of two parts, namely, hoist and base. The hoisting machine consists of the frame, the hydraulic lifting system and the door turning mechanism. Work, the first hoist of the hopper and the barrel buckle, start lifting the lever, the material door and the barrel with the rise, start the flip lever, the bucket can turn 180 degrees, the bottom of the barrel upward attitude and move To the desired location, the use of material on the door butterfly valve, it is easy to add the necessary materials in the process equipment.
Technical specifications
|
Model Specification \ Parameter |
H | A | D | H1 |
| TJG-50 | 2050 | 650 | Φ485 | 2900 |
| TJG-100 | 2050 | 750 | Φ590 | 2900 |
Technical specifications
| name | quantity（kg） | Specifications (barrel diameter × height) | Wall thickness（mm） |
| Bucket | 50 | Φ485×460 | 0.8 |
| 100 | Φ590×550 | 0.8 | |
| Bucket special car | 50-100 | Φ500×600 |
